We do not currently have detailed product information for this part.
Swagelok 43 series plug valves are manufactured of lightweight PFA.
Working Pressure Temperature • Liquid Service • Gas Service Flow Coefficient Body Material End Connections
A 316 stainless steel panel mount bracket that enables back or front mounting is available factory assembled or in a kit for field assembly.
Every 43 series PFA plug valve is factory tested with nitrogen at two times the rated pressure for leakage at the seat to a maximum allowable leak rate of 0.1 std cm3/min. Body seals are tested with helium at two times the rated pressure to a maximum allowable leak rate of 1 × 10–3 std cm3/s.
Every 43 series PFA plug valve is cleaned and packaged in accordance with Swagelok Standard Cleaning and Packaging (SC-10).
